Integration of face capture, Recognition function, infrared temperature measurement function
Temperature anomaly alarm: non-contact body surface temperature detection within one second, Detection distance 0.4-0.7 meters, Temperature error range ±0.4°C, Abnormal temperature linkage acousto-optic alarm and access control equipment
Support living face detection, effective prevention of photos and video spoofing
Face database can reach 10,000pcs, flexible face template import, support single, batch image file import and real-time capture import
Provide query after login, set integrated parameters, view real-time monitoring and face comparison image
Support face types of ordinary people, whitelist people, blacklist people, etc.
Support recognize result linkage I/O, wigan port output, voice broadcast
Can be widely used in access control channels, wall-mounting attendance and other scenarios.
![P2p Long-Range 0.4-0.7 Meters Indoor Outdoor Infrared Body Temperature Detector](https://img3.grofrom.com/weathtempco/98fccf4e36fea1e602dd62043c901bf5.webp)
![P2p Long-Range 0.4-0.7 Meters Indoor Outdoor Infrared Body Temperature Detector](https://img3.grofrom.com/weathtempco/27a6adfa22ec4b85fe8997dc878cb866.webp)
![P2p Long-Range 0.4-0.7 Meters Indoor Outdoor Infrared Body Temperature Detector](https://img3.grofrom.com/weathtempco/cd7613a1e1a20a0691df25fe237dbbc3.webp)
![P2p Long-Range 0.4-0.7 Meters Indoor Outdoor Infrared Body Temperature Detector](https://img3.grofrom.com/weathtempco/25a1d7fb8f5fa4ae174338b99f831674.webp)
![P2p Long-Range 0.4-0.7 Meters Indoor Outdoor Infrared Body Temperature Detector](https://img3.grofrom.com/weathtempco/ceb6152fd5949110da49a1c9f8ac5143.webp)
![P2p Long-Range 0.4-0.7 Meters Indoor Outdoor Infrared Body Temperature Detector](https://img3.grofrom.com/weathtempco/a8e4ec5bc2ac3b6b395a368458126398.webp)
![P2p Long-Range 0.4-0.7 Meters Indoor Outdoor Infrared Body Temperature Detector](https://img3.grofrom.com/weathtempco/d7516e7389708835acdb069b049d1504.webp)
Temperature anomaly alarm: non-contact body surface temperature detection within one second, Detection distance 0.4-0.7 meters, Temperature error range ±0.4°C, Abnormal temperature linkage acousto-optic alarm and access control equipment
Support living face detection, effective prevention of photos and video spoofing
Face database can reach 10,000pcs, flexible face template import, support single, batch image file import and real-time capture import
Provide query after login, set integrated parameters, view real-time monitoring and face comparison image
Support face types of ordinary people, whitelist people, blacklist people, etc.
Support recognize result linkage I/O, wigan port output, voice broadcast
Can be widely used in access control channels, wall-mounting attendance and other scenarios.
VL-W05FEW | |
Screen | |
Size | 7 inch, full-angle IPS LCD screen |
Resolution | 1280x800 |
CAMERA | |
Type | Design of double camera |
Sensor | 1/2.8" SONY starlight CMOS |
Resolution | 1080P@30fps |
Lens | 3.6mm*2 |
White balance | Auto |
Face exposure | Support |
Mirror | / |
Image settings | Exposure, gain, contrast, saturation and brightness adjustable |
ACCESSORIES | |
Complementary light | IR light, LED white light |
Identity module | Support ID card recognize module optional |
Loudspeaker | Support voice broadcast after successful recognition |
Network module | Built-in wifi Module |
Video | |
Video compression | H.265/H.264 |
Encoding features | main stream::1920x1080@30fps,sub-stream:D1@30fps |
Max. Resolution | 1920x1080 |
Video bit rate | Constant bit rate, variable bit rate (16kbps~8000kbps) |
Video type | Complex stream/ Video stream |
FUNCTION | |
Network protocol | IPv4, TCP/IP, NTP, FTP, HTTP |
Access protocol | ONVIF, RTSP |
Safe mode | Authorized user name and password |
Face recognition | Support |
Event linkage | Capture TF card storage, FTP upload, alarm output linkage, wiegand output linkage, voice broadcast |
Remote upgrade | Support |
Others | / |
FACE RECOGNITION | |
Detection type | Support lving face detection, effective prevention of print photos, phone photos and video spoofing |
Face detection number | 0.3-1.3m, support detection target size filter adjustment |
Recognition face size | Pupils distance ≥ 60 pixels; Face pixel ≥150 pixels |
Face database capacity | Support built-in ≤ 10000 faces; support black/white list |
Posture | Support side face filter, comparable within 20 degrees in vertical and 30 degrees in horizontal |
Shelter | Recognizable with ordinaryglasses and short bangs hair |
Expression | Recognizable with slight expression |
Capture/comparison rate | Capture rate≥98%(meet the above conditions); Recognition rate≥95% |
Response speed | ≤1s |
Face / card recognition | Support 1:1 / 1:N mode |
Local storage | Support storage of more than 100,000 capture and recognition records |
Recognition area | Full image recognition, support zone optional setting |
Upload mode | FTP , HTTP upload, SDK function calling upload |
Temperature Detection | |
Sensor interface | iic interface |
Range of detection | 32ºC~45ºC |
Error range | ±0.4ºC |
Voice broadcast | Support face recognition broadcast and temperature detection alarm |
Detection distance | 0.3-0.5M |
INTERFACE | |
Network interface | RJ45 10M/100M network adaptative |
Alarm input | 1CH |
Alarm output | 2CH |
RS485 | Support |
TF card | Max.support 128G local-storage |
USB | 1CH |
Wiegand interface | Support wiegand 26,34,66 protocol |
Reset | Support |
Tamper switch | Support |
GENERAL | |
Operating temperature | -10°C ~ 50°C |
Operating humidity | 0%-90% |
Power supply | DC12V |
Power consumption (max) | ≤12W |
Dimensions(mm) | 399mm(H)*138mm(W) |
Istall type | X86 box |
