Brief Introduction
CKT10000A/CKT8000/CKT5000/CKT3000/CKT2000/CKT1000/CKT500/CKT300/CKT200 is precision LCR meter for inspection of all kinds of electronic components. Using 7 inches LCD TFT display. It is a high-speed, broadband, 6-bit test resolution of the impedance measuring instrument, multi frequency points and 0.05% accuracy can meet the requirements of various occasions' component parameters detection. It is a high cost of quality testing equipment.
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/da47d46832b230d4e4373479a973f197.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/67f5385bdd144847a396f7b173c9a688.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/69d50a207ac5f29ed3bdcdbe7bc1e572.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/127c6bf9eb54dd5bc86e9214b6c97d6c.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/97aa1511170db2409a1e6c15f68e1719.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/e599368a3426d87328e021260525de2d.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/c56bfcc88a8e08d05021cf6600fe6cc0.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/7a46f1dcf5e6c9bd6ff1430e29245478.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/116bf38d149580ae38366ef035c95ed4.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/a2b598330383674fca82c5eed97d6106.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/73606f372863756ab38e57758f7934f4.webp)
![Digital Lcr Meter Capacitance Meter Resistance Meter Inductance Meter (Model CKT200)](https://img3.grofrom.com/weathtempco/0105e60729b317f04764a6aa3e34f2f1.webp)
Chuangkai Electronic Co., Ltd is leading company specialized in producing, developing & selling various types of measuring instruments and testing equipment, such as temperature data logger, LCR meter, DC resistance tester (micro ohm meter), digital power meter, power supply, transformer tester, battery tester, programmable DC electronic load, charger, temperature controller, tachometer, high voltage signal-amplifier, power amplifier, etc.
FAQ:
Q. How is your company's product after-sales service system?
A. The product warranty period is 12 months, we can provide lifetime maintenance. We have professional pre-sales and after-sales teams that can respond to you within 24 hours to resolve technical issues. We provide one-to-one after-sales service.
Q: Can you customize it?
A: Yes, we accept customization according to customer's specific requirements.
Q. How long is your lead time? If I want to customize instruments, how long will it take?
A. When order quantity is 1-10 units, we have ready stock goods, we can ship out within 3-5 working days after receipt of deposit; products required new production of common materials, usually the lead time is about 10-15 days; products requiring new production of special and rare materials, usually the lead time is about 20-30 days.
Q. What payment method do you accept?
A. Our company accept payment method of T/T (bank transfer), Western Union, PayPal and so on.
Q. What package do you use for your products? What shipping method do you use?
A.1. Our company use standard exporting carton for packing. 2. We ship via express courier (door to door service), by air, and by sea according to customers' requirements.
For more questions, please feel free to send inquiries to us.
CKT10000A/CKT8000/CKT5000/CKT3000/CKT2000/CKT1000/CKT500/CKT300/CKT200 is precision LCR meter for inspection of all kinds of electronic components. Using 7 inches LCD TFT display. It is a high-speed, broadband, 6-bit test resolution of the impedance measuring instrument, multi frequency points and 0.05% accuracy can meet the requirements of various occasions' component parameters detection. It is a high cost of quality testing equipment.
SPECIFICATIONS | |
CKT10000A/CKT8000/CKT5000/CKT3000/CKT2000/CKT1000/CKT500/CKT300/CKT200 Precision Digital LCR Meter | |
Parameters | | Z|, |Y|, C, L, X, B, R, G, D, Q, θ, DCR |
Display Mode | Direct,Δ,Δ%,V/I |
Basic Accuracy | 0.05% ± 5 dgt, DCR:0.1% |
Frequency | CKT10000A: 10Hz~10MHz CKT8000: 10Hz~8MHz CKT5000: 20Hz~5MHz CKT3000: 20Hz~3MHz CKT2000: 20Hz~2MHz CKT1000: 20Hz~1MHz CKT500: 12Hz~500KHz CKT300: 12Hz~300KHz CKT200: 12Hz~200KHz |
Display Range | Z,X,R:0.01mΩ~99.9999MΩ DCR:0.001mΩ~99.9999MΩ Y,G,B: 0.00001µS~99.9999S C:0.00001pF~9.9999F L:0.00001µH~9999.99H D:0.00001~9.9999 Q:0.00001~9999.9 q(rad): -3.14159 - 3.14159 q(deg): -179.999° -179.999° |
Source Resistance | 30Ω, 50Ω (CKT1000/2000/3000/5000/8000/10000A), 100Ω,10/CC |
Range | Auto, Hold, Manual selection |
Comparator | 11-bin sorting (9-bin GD, 1-bin NG, 1-bin AUX) |
Signal Level | 10mV~5V (CKT1000, CKT500/300/200: 5 mV~2V), accuracy: 10%; Constant level:10 mV~1 V, accuracy:5% |
DC Bias Source | -5V~+5V; -100mA~+100mA (CKT1000, CKT500/300/200: 0V,1.5V, 2V), accuracy: 1% |
Trigger Mode | INT, MAN, EXT, BUS |
Speed | 200t/s, 12t/s, 3 t/s, 1-255 times average is available; CKT1000/CKT500/CKT300/CKT200: 75t/s, 12t/s, 3 t/s |
List Test | 10 group frequency and level scanning measurement |
Adjustment | Open / short / load |
Files | U disk copy screen, real-time data storage, which can support the FAT16 format, FAT32 file system |
Interface | RS232C, USB HOST, USB DEVICE, HANDLER, Headset interface, Foot switch interface |
Others | The frequency response curve analysis; Can save the file to the instrument or U disk |
GENERAL FEATURES | |
Power Supply | Voltage: 110V/220V; Frequency: 50Hz - 60Hz |
Size and Weight | 375mm(W)*135mm(H)*350mm(L) 7kg |
ORDERING INFORMATION | |
Accessories | Kelvin Test clip; Test fixture; Short-circuit slice; RS232 Communication cable; AC Power Cord |
Optional | SMD patch test fixture; SMD patch test clip |
